EXPLORER™ ANALYTICAL Flagship Balances from OHAUS EX224/AD

Description

Applications

Weighing, Parts Counting, Percent Weighing, Checkweighing, Animal/Dynamic Weighing, Filling, Totalization/Statistics, Formulation, Differential Weighing, Density Determination, Peak Hold, Ingredient Costing, Pipette Adjustment, SQC

Display

5.7″ (145 mm) Full-color VGA graphic touchscreen display with user-controlled brightness

Operation

AC adapter (included)

Communication

RS232 and USB (included) or second RS232/Ethernet (accessories sold separately) . GLP/GMP data output with real-time clock.

Construction

Metal base, ABS top housing, stainless steel pan, glass draftshield with top mounted side doors & flip/sliding top door, illuminated up-front level indicator, weigh below hook, security bracket, calibration lock, 4 touchless sensors, in-use cover

Design Features

Selectable environmental filters, auto tare, user selectable span calibration points, software lockout and reset menu, user selectable communication settings and data print options, user definable project and user IDs, auto standby, up to 14 operating languages

SPESIFICATION

Maximum Capacity	220 g
Readability	0.1 mg
Pan Size	3.5 in (90 mm)
Internal Calibration	AutoCal™ – Automatic
Draftshield	Included
Auto Door	Included
Auxiliary Display Model	Available as an Accessory
Battery Life	Not applicable
Communication	Ethernet (Available as an Accessory); USB (Included); RS232 (Included)
Dimensions	15.5 in x 13.8 in x 9.1 in (393 mm x 350 mm x 230 mm) (LxHxW)
